Digital module
CASE
Material
The case and bezel are made from Titanium and finished in black. Fastened with eight screws, the back of the case is stainless steel while push-buttons are brushed stainless steel with anodized inserts in aluminum.
Case Dimension
Diameter 45 mm, thickness 17,50 mm.
Band lug width 22 mm.
Case and Bezel
Titanium with black DLC treatment.
Case Back
Stainless Steel with a deep etching engraving on case back.
Buttons
Push-buttons in brushed stainless steel with anodized inserts in aluminum.
Crystal
Domed Sapphire Crystal, anti reflex treated on outside.
Water Resistance
Water resistant according to ISO 22810 (NIHS 92-20).
Pressure resistant to 10 atm.
TECHNOLOGY
General
The Caliber HR 2012-1 is a highly efficient electronic movement by Halda incorporating an automatic light sensor, a power save mode and a battery reserve indicator. This runs the software developed by Halda together with racing professionals – Race Pilot.
Electronic Movement Calibre
HR 2012-1.
Software
Software RP-A, RACE PILOT Version A.
Processor
Low power consumption microprocessor.
Push Buttons
3 push buttons with an easy to use interface.
Accelerometer
Three-axis accelerometer measuring G-Force.
Battery
Minimum lifetime 2 years.
Display
Custom designed LCD display with LED backlight.
Light Sensor
Integrated automatic light sensor.
FUNCTIONS
Racetrack
Featuring information from 150 of the world’s most popular racetracks.
Race Chronograph
Measuring lap time and average speed of two cars simultaneously with accuracy down to 1/100 of a second.
Countdown to Race
Time remaining to next race displayed with days, hours, minutes and seconds.
FIA Formula 1 Countdown
Warning system of time remaining until Formation Lap, according to the Formula 1 regulations of Fédération Internationale de l’Automobile (FIA).
Dual Time
Showing local time andpreferred world time as well as day, date and week Battery lifetime and software version is also visible within this function.
World Timer
UTC and DST, with ability to display time and time zone of the 193 countries connected to UN.
Alarm Clock
With possibility of setting the alarm to sound once, every day or weekdays (Reveille).
Timer
24 hour timer.
G-Force
Three axis accelerometer measuring G-forces in three different directions.
Backlight
Integrated automatic light sensor.
Alarm Signal
Case-back with a resonance system for amplified sound level and with a sound profile with frequencies between of 2,5 –8 kHz.
Perpetual Calendar
Day, date, year and week indicator.
Power Save Mode
With battery reserve indicator.
